Miller Nitro 6000 Series

  • Miller Nitro 6000 Series

    Miller Nitro 6000 Series is the ideal self-propelled sprayer for demanding operations. A wide range of model, horsepower options, boom options and precision technologies available.


    As locally owned and operated businesses, our strong network of franchisees are part of their local community and understand the needs of their local customers.


    The Nitro 6000 Series is not an average sprayer. It's a class-leader in so many ways. The over six feet of ground clearance allows for late season spraying in tall crops, ensuring critical yield-boosting applications can be made when you need them to be. The front cab and boom configuration give you a commanding view of your entire operation. Watch every nozzle and navigate every obstacle in the field without ever looking back. And with the Nitro's high clearance and safe, pressurised, charcoal filtration SprayView cab, you'll never have to worry about airborne chemical contamination in the operator environment. The Nitro's Quick-Attach versatility gives you the power of maximum asset utilisation. With Quick-Attach, you can drop the spray boom in mere minutes and attach a grain swather, a corn detassler, or a Miller Injection Toolbar without having to incur the capital costs associated with running another power unit. Your bottom line will thank you for the efficiency you gain from your Nitro.

    Miller Nitro 6000 Series Specification

    SprayView Cab
    "Ultra Quiet" cab with air ride, pressurisation, charcoal filtration, heat/AC, AM/FM/WX w/CD, 2-way tilt/telescope steering wheel, sun visor, cloth air ride seat with folding instructional seat, Chassis Monitoring System

    Premium SprayView Cab
    All standard SprayView features PLUS Grammer Evolution suede leather seat with air-ride suspension, heated and cooled.  Leather wrap steering wheel, Auto Climate Control, Bluetooth XM stereo with 4 speakers, lighted cup holder, deluxe dome lights, X-Grip for cell phone, rear camera.

    200 Amp

    Fuel Tank
    150 gallon (568 L)

    Cooling System
    Efficient Single Pass "Stacked" (not layered), hydraulically driven fan with reverse option

    Torq-Trac® hydrostatic drive system with Twin Sauer Danfoss heavy duty pumps

    Auxiliary Hydraulic Circuit
    Choose 26 GPM (98.4L/min) or 44 GPM (166.5L/min)

    UltraFlo Hydraulic Pump Option
    Independent 42 GPM

    Speed Ranges
    0 to 32 mph (0 to 51 kph) with 4 programmable speed ranges

    Service Brake
    4-wheel dynamic internal wet disc and oil cooled

    Park Brake
    4-wheel spring applied

    Hydrostatic with two steering cylinders, no tie rods

    Standard 2 - Wheel Steering
    15' (4.5m) radius

    Optional 4 - Wheel Steering
    21' (6.4m) in 2 wheel steer mode and 15' (4.6m) in 4 wheel steer mode

    Tread Width Adjustment
    120" to 160" (305 to 406 cm) hydraulic adjustment standard

    HydraLink™ Suspension
    4-wheel independent, full suspension travel of 20" (51cm), hydraulic leveling/shock absorbers, auto-leveling for each leg

    Ground Clearance
    74" to 76" (188 to 193 cm) varies with tire size

    Product Tank Options
    1200, 1400, or 1600 gallon (4542, 5300, or 6056 L) stainless steel

    Rinse System
    Standard manual or optional electric in-cab controls, 150 gallon (568 L) poly tank and 2" QuickFill connection

    Product Pump Standard
    Hypro 9306C - 210 gpm @ 80psi (795 L/min @ 5.5 bar) capacity at the pump

    Product Pump Option
    High capacity Hypro 9307C - 310 gpm @ 80psi (1,173 L/min @ 5.5 bar)

    Foam Marker Option
    Injection System - uses water from rinse tank - in-cab controls - 3 gallon (11.3 L) foam concentrate tank
